2020-03-30 Bilge Sensor Detail

This document assumes this is not your first Arduino implementation. If so please contact me for specific implementation help

This is a home-built sensor is the latest addition aboard Magnolia. The purpose is to collect the primary bilge pump run frequency and run duration. Magnolia has a traditional stuffing box and the bilge is MOT dry. Our bilge pumps have always popped on as required, but I never had any understanding of how long and how often. We now have that data.

Hardware: The sensor itself is very simple. There is an ESP-32S Processor Board , 25V Voltage Detector, 1.3″ IIC I2C Serial 128×64 SSH1106 OLED LCD Display LCD Module along with a Breadboard and connecting jumper wires. There is also a small push button to enable downloading of new software to the ESP-32. All items are readily available on Amazon.

The below Fritzing file is availble at: https://drive.google.com/open?id=16hcxkLP8NNJhmCP00F-pebd04jTqR8gh

I used some Piggy Back Spade Quick Splice Crimp Terminals Connectors to attach the sensor to the back input of my Bilge Pump Control Panel ensuring the sensor was receiving power whenever the bilge pump light illuminated.

Software: Three of the sensors on Magnolia use the same codebase and applicable sections are controlled pre-processor directives. The specific Bilge Sensor code is available at: https://drive.google.com/open?id=1qqcYzlBnlc_VfFYIYtKl8uIyEPSApwfq

The following paths are reported to the Signal-K Server:

environment.inside.bilge.currenttime “19:32:28”
environment.inside.bilge.lastruntime  “19:30:44”
environment.inside.bilge.runcount                  110
environment.inside.bilge.runduration  “04:02”
environment.inside.bilge.rundurationmils            242
environment.inside.bilge.status                “Stopped “

2020-03-28 — (Geek Warning) – MV Magnolia Data Collection & Distribution System with Signal-K

Vessel: Magnolia is a classic 42′ Kadey Krogen trawler with stabilizers, hydraulic bow thruster, hydraulic bow and stern anchor windlass. She is recreational vessel built to commercial like standards from her Lugger main-engine to her extensive hydraulics and redundancy provided by her 16Kw Lugger powered Northern Lights generator.

Background: Coincidentally when Magnolia’s solar array system was upgraded in 2019, a new data exchange format was emerging called Signal-K. Being ever curious, an idea of an in-depth data collection system came into focus. Research, along with a lot of trial and error, I got a Signal-K (http://signalk.org/ ) Server running on a RaspberryPi. (Before this started I did not even know what a RaspberryPi was.) After getting the server to receive Magnolia’s Raymarine Navigation Data via an Actisense USB Adapter, it was time to figure out how to get a “home-grown” sensor and Magnolia’s data into the server.

I wanted to build my own sensors and research led me to an Arduino processor board specifically, the Mega2560. I made this initial decision based on the large number of hardware inputs at the 5 volt level. The downside of this choice was there was no integrated Wifi. An ESP8266 chip with Wifi capability could be integrated using the serial interface. In the end I found the Mega2650 was not a great choice because I could not get good reliability from the Wifi nor solid interfaces from NTP Time Server. This is probably not the fault of the board but inexperience of the developer.

As sometimes happens on boats in the midst of this project a less fun piece of equipment failed. Our grey-water tank control gave up the ghost and died. Sadly, the only product that really met requirements was a “Tank Sentry” product in excess of $1000! My attention quickly turned to a homemade Signal-K-based system.

Since I had never tried anything like this before I wanted to have two isolated level sensors. I wanted to make sure we could still use the sensor if the “smart” part should fail! I started with a float switch and several Non-contact Digital Water Sensors. I eventually abandoned them and went with a second traditional resistance float switch. The control panel was made with some teak, LEDs and switches that I had on hand. An upgrade could be in the works, but waiting on inspiration for it. The Tank Sensor Control system is based on the Mega2560 controller board instead of the later adopted ESP-32 controller board.

The Tank Sensor & Control measures tank level, displays the measured levels via the installed LED lights and will empty the tank either manually, or automatically under control of the Arduino controller. In addition the following data is sent to the SignalK Server via UDP over WIFI.


– Current time aboard the Arduino is reported. – Current humidity inside the Arduino hardware case.

Current temperature inside the Arduino hardware case.

– Ships Battery Voltage

– Secondary Sensor Tank Level (Only 2 values available from this sensor, high or low)

– Primary Sensor Tank Level (4 values available from this sensor, high, high-medium, low-medium or low)

WilhelmSK is one method to display SignalK data. Note that the Grey-Water tank data is highlighted in red below.

I think that kind of explains how we got here and now I will provide a more in-depth discussion of what we have implemented aboard Magnolia.

Current Implementation:

The above diagram presents the interconnected functions of the Magnolia Data Connection System. The Signal-K Server running on a RaspberryPi is at the center of the diagram.

Raspberry Pi/Signal-K Server: The Raspberry Pi (https://en.wikipedia.org/wiki/Raspberry_Pi ) itself is a single board computer which provides the same functionality as any other computer although two extra attributes make them very desirable for this application. 1. Cost – relatively CHEAP! 2. Power – power consumption is low, powered by 12v supply. As far as computer processing power, the device provides all the capabilities required by the Signal-K server software. The Signal-K server software provides a mechanism to transfer, store, and distribute data focused on a boat environment. The Signal-K server software is best described here (http://signalk.org/overview.html).

The server receives inputs from various sources:

Actisense NGW-1 NMEA 2000 Gateway: (https://www.actisense.com/products/nmea-2000-gateway-ngw-1/ ) This commercial device interfaces the Signal-K Server to the boat’s NMEA network. Garmin, Raymarine are examples. The data transmitted can be any combination of Navigation, Depth, Wind and can include engine and other systems data.

Bilge Sensor: This is a home-built sensor is the latest addition aboard Magnolia. Its purpose is to collect the primary bilge pump run frequency and run duration. Magnolia has a traditional stuffing box and the bilge is not dry. Our bilge pumps have always popped on as required, but I never had any understanding of how long and how often. We now have that data. (ESP-32 Processor)

Battery Sensor: Another home-built sensor that collects current and voltage data associated with the house battery bank. In addition electric current data is collected from solar arrays. A standard electrical shunt device is used to collect current data coming from the Outback Solar Controller and another shunt is used to monitor total current coming and going to the house bank batteries. The sensor also includes reporting of the Battery Sensor current time, temperature and humidity as well. (ESP-32 Processor)

Tank Sensor: This sensor/controller is pretty well described above in the opening section. (Mega2560 – Processor)

Solar Sensor: This home-built sensor is very similar in functionality to the Battery Sensor. The Solar Sensor collects Solar Data coming from the Solar Arrays BEFORE it is fed into the Outback Controller. Magnolia has a battery on the fly-bridge used to power the Dinghy Hoist. This battery is charged via a separate solar panel and monitored via the Solar Sensor. (ESP-32 Processor)

The above paragraph outlines how data is collected using the various sources but how it is viewed and utilized is where the real value of these systems come into play.

WilhelmSK (https://www.wilhelmsk.com/ ) (from webpage) is a commercial highly customizable boat instrument display that uses the Signal-K protocol (signalk.org) to show information from your boat’s sensors on your iPhone, iPad, Apple Watch or AppleTV. On Magnolia we primarily use this application in the Pilothouse to display our Signal-K collected data. Essentially there are two separate displays. One is designed for Navigation Related Data and the other for Systems Status Data.

The Navigation Data Screen provides all of the usual data but a couple of items require special notice. Magnolia has two depth transducers installed (one port, the other starboard). One weakness of Raymarine is it could only use one transducer at a time. Signal-K and the WilhelmSK application allow me to display data from both transducers at the same time. In addition, unlike any display in Raymarine we are able to display Pitch, Roll and Yaw data being generated by the 6-Degree of Freedom (DOF) gyro. This display also shows the current data from the Bilge Sensor as described above. The anchor distance from the Signal-K embedded anchor alarm can be displayed as well. Last but not least on Raymarine Systems, the autopilot can also be controlled as well.

The Systems Status Data Screen is essentially where the data from Battery, Solar and Tank Sensors is displayed. As previously described the left hand side of the screen provides grey-water tank related data. There is one tank but two sensors. The granularity of the sensors is different and that is why they measure slightly differently. Everything is a compromise. The electronic tank sensor is located at the far-end of the forward 12v bus so we also report back the battery voltage measured at that location. There is also a temperature/humidity sensor and a real-time clock reported to the server as well.

The center section of the display is related to the Solar Sensor. This is solar data before it has reached the Outback Solar Controller, which is essentially raw from the panel data. The panels ideally operate at 22v and produce approximately 10amps or 225w (times 5 panels). The collected data makes it very easy to see how the panels are operating in relation to specification.

The section on the far right again is similar to the center in that it primarily shows solar data, but this data is AFTER the energy has been passed through the Outback Solar Controller. There are two electric amp displays, Solar and Battery. The Battery display is a measure of what is happening in the battery bank, i.e.are we making more energy than we are using either through solar, the generator or even the alternator. The Solar Current measures the solar panels contribution to the battery status. For example, the ship’s equipment may be using a -10amp load but if solar is producing +20amps it will appear +20 in the Solar Current Display and +10 in the Battery Current Display.

Amazon Alex – (https://www.amazon.com/Scott-Bender-Signal-K/dp/B078X362VK ) When you connect your Signal K Node server to the Signal K cloud, you can use Alexa get information like wind speed, battery charge, tank levels, etc.I really do not use this functionality but it makes a great parlor trick!

Grafna / Influx – I neglected to include this item from my overall chart. This section really begins to show the super strength of Signal-K and how sharp the developers of this server really are!

Influx (https://en.wikipedia.org/wiki/InfluxDB): “InfluxDB is an open-source time series database (TSDB) developed by InfluxData. It is written in Go and optimized for fast, high-availability storage and retrieval of time series data in fields such as operations monitoring, application metrics, Internet of Things sensor data, and real-time analytics. It also has support for processing data from Graphite.”

Grafna (https://en.wikipedia.org/wiki/Grafana): “Grafana is a multi-platform open source analytics and interactive visualization software available since 2014. It provides charts, graphs, and alerts for the web when connected to supported data sources. It is expandable through a plug-in system. End users can create complex monitoring dashboards[4] using interactive query builders.”

The developers of Signal-K provided a mechanism for all that boat-reported data to be stored in an Influx Database. Using a tool like Grafna, a dashboard like the simplistic one below can be created EASILY! My simplistic dashboard below shows the items I am curious about on a day to day basis. The top window tells me about the energy the solar panels have produced over the last 48 hours measured in watts (instantaneous). To the right, the next display tells me about production over the last month measured in watt-hours. The House Battery Bank Voltage is straightforward and corresponds to charging action of the solar panels from above. As I said the Bilge Pump Sensor was just recently brought on line, but as you can see it shows the number of times it turned on and the total run-time. You can see in the chart below what day Magnolia was underway. Still figuring things out here. Last but not least is the voltage of the Dinghy Hoist Battery. Its voltage too corresponds to solar charging but we do have a small charger in place to ensure the battery’s availability. Having the data available to understand trends is extremely useful.

Node-Red / MQTT – Before I started with Signal-K I had never heard of InfluxDB, Grafna nor these next two topics. The more I learn the more I am impressed with the Signal-K developers. When it comes to usefulness, this in my mind is where things go completely off the charts.

Node-Red (https://en.wikipedia.org/wiki/Node-RED): ”is a flow-based development tool for visual programming developed originally by IBM for wiring together hardware devices, APIs and online services as part of the Internet of Things.”

MQTT (MQ Telemetry Transport) (https://en.wikipedia.org/wiki/MQTT): ”is an open OASIS and ISO standard (ISO/IEC PRF 20922) lightweight, publish-subscribe network protocol that transports messages between devices. It is designed for connections with remote locations where a “small code footprint” is required or the network bandwidth is limited.”

The above paragraph says a lot, but I will use the below as an example of what Magnolia is doing. On the first line of the chart below you see the Tank Sensor Current Time. This is the time message the Grey-Water Sensor sends to the server. When the server receives the time message the server sees that Node-Red has subscribed to that message and it enters my custom processing flow. Inside the flow that message is used to reset a watch-dog timer. That means that if the message is not received in the prescribed three minutes the flow automatically sends a message to the Grey-Water Tank Alarm which plays an audio message that starts with an alarm and then a message saying “Grey-Water Sensor Appears Offline.” In addition a SMS Text Message is sent to my phone. Thanks to Jeff Siegel who opened my eyes to another technology, PHP web scripting, which makes this functionality possible! Having that alarm go off sure beats a grey-water tank from overflowing into the bilge! The possibilities are endless. I might point out the “Blow Dryer Delay” implemented in the Battery Current. The purpose of this processing is to send an alarm if, for example, a high current appliance is left turned on or if shore power is lost and the air-conditioner is on. Obviously the alarm is not allowed to go off while the blower dryer is running…btw, that is an agreed on five minute timer! 🙂

There is similar processing throughout the flow, but the smallest box on the flow is the most powerful. The lavender box marked “mqtt” is the coolest. That little box collects data sent to it and forwards that data to a MQTT broker that lives out on the internet and allows that data to be forwarded to my phone. As previously shown, alarm SMS Texts can be sent, but in addition, actual data can be forwarded to my phone as well.

The phone screen captures below allow me to see what is going on aboard Magnolia from any place in the world. We can see: status of the batteries, solar, how far we are from the anchor drop location and how deep the water is! Essentially any data on the boat is available anywhere in the world. For me this was the ultimate endpoint.



Cost: In dollars this technology is essentially free. All of the software is free (WilhelmSK is $19.99 and worth hundreds!) and the hardware I have purchased is less than $250. The cost in hours is immeasurable, but the satisfaction is priceless.

Thanks: The development team at Signal-K are rock stars! The product they are producing is amazing, the choices they have made and implemented provide the flexibility to do anything we boat geeks can imagine. Special thanks to Scott Bender and Teppo Kurki who patiently helped me through many technical challenges. I cannot forget to thank my friend, Jeff Siegel, who is always willing to talk through ideas and implementations.

Dedication: This post is dedicated to all the people and teams I have been blessed to be part of over this lifetime. The list is too long to enumerate but it started with Cam-Bake Productions and a stupid little casino game aboard this Navy Ship. What a freaking adventure!

2020-03-26 Wow What Just Happened?? + Mark&Mary Visit, FL Keys, Disappointments….

I cannot believe it is only us, but I find myself asking, what the ….. just happened? Remember back, I mean way back like three weeks when those that did, went to work and life was normal…this last segment of our trip was filled with excitement and some great surprises for it all to end in disappointment. I imagine we all have been going through the same thing over the last couple of weeks.

We departed Palm Beach headed for Fort Lauderdale on the outside…we were having such a great passage we decided to press on to Miami and enable to miss a number of bridges on the inside.

Departing Palm Beach Lake Worth Inlet at dawn.

The Breakers from the otherside…for Dan and Lori

It was a marvelous day to be on the water as you can see entering Miami inlet…we did have the current against us but it beat bridges anyday!

We had not been to Miami in a number of years and never aboard Magnolia-M only the sailboat. Not planning to be in Miami today we reached out to friends on Kismet (Jim & Laurie) who we knew were recent visitors. In the course discussions Jim pointed out there was bridge we could not get under (no sailboat mast) which made our arrival literally 10 times easier!!! Thanks Jim!

We anchored in-between Hibiscus & Star Islands ( https://en.wikipedia.org/wiki/Star_Island_(Miami_Beach) ) & ( https://en.wikipedia.org/wiki/Hibiscus_Island ) – note the Wikis are worth reading, couple fun facts in each. Also to note this location just across from Dodge Island Cruise Ship docks.

Homes on Star Island. There is a constant stream of tour boats….I mean like 20 a day so they must have the scoop on who owns what…

Downtown Miami with the cruise-ship terminal to left. It was interesting to me how many ships come and go…it really was amazing and surprised to see how many were still going out at this point.

Like I said this was the beginning of the Coronavirus so we went a shore but kept our distance. We did stop at the Publix Grocery store for a top…it was mobbed and that was our last social interaction for the duration! We did have a nice beach walk and no one can say Miami is NOT cool…even the fire stations!

In addition to the beach there was a stop at the Botanical Gardens (https://en.wikipedia.org/wiki/Miami_Beach_Botanical_Garden) which were quite lovely and a respite from the hustle and bustle of the streets.

A high school girlfriend of Annettes, Mary and her husband lived nearby in Coral Gables. Our current location was not conducive to a visit from non-boaters but and alternate plan was hatched.

If we went down and around to Key Biscayne and inside No-Name Harbor thought that might be a much safer alternative than a long dinghy ride. We had never been inside the harbor because its usually crowded that is not our thing but and opportunity not to be missed.

Magnolia arrived early and yes it was crowded but not for the settled conditions we were expecting.

While I did my thing aboard and Annette did some exploring ashore and found the beach t be quite nice!

As it turned out the park was closing because of the Coronavirus at 5pm that day and remain closed for the duration. Mark and Mary performed some heroics and made the cutoff time with moments to spare. The ladies had a lovely time catching up and comparing notes.

Mark and I shared a cigar on the back deck and that too was fun. Really nice people and looking forward to our next visit!

Our friends Jack & Kathy along with their friends Rich and Moe were planning to meet us in the Florida Keys for a week of non-sense….all were very much looking forward! As no one had a clear idea where this was all going Magnolia got underway for the couple day 100 mile trip south. There was also a couple days of bad weather forecast. None of which was crazy or weird just part of a plan. The problem with the Keys is there is VERY limited places to get good protection from east winds. Rodriguez Key near Key Largo is one so that was our first stop.

With the weather approaching we continued south to Channel 5 which would allow us to transit to the west side of the keys for the forecast winds.

We had never take the sailboat through here…cannot remember if it was a bridge height issue or a depth issue. Both of which we have a lesser issue than with the sailboat.

There is an R/V Park – Marina – Restaurant located ashore. We sensed where this virus thing was going so we took the opportunity to get a ashore. The dockmaster was not exceptionally nice but lucky the restaurant owns a couple of slips at the marina… we got our first sense of where this was all going with the wide table separations and distance the servers served from…all very wise for sure.

Magnolia was anchored out by herself until to the two vessels came in. They could have stayed a but further off but if Magnolia is anchored here it MUST be good so they came closer than I thought necessary.

There was exceptional water down there so we took advantage and made fresh water for our tanks during every generator run,

This referred to as Chill-Slacking!!!

We all finally came to the realization there was not going to be a Florida Keys Tennar/Dinn/Baker nonsense extravaganza. There was only one thing to do but break out a good bottle of wine and good steak and fire the barbie!!!

With the keys heading towards shut down there as no reason for Magnolia to continue south towards Marathon.

We saw a couple good weather windows coming and also our mentors Greg & Marie on Second Sally were getting ready to head from St Thomas to Lake Worth which meant we might be able to meet up with them as well.

We passed this mini-mega heading south. Not exactly sure where he was headed but seemed odd under the circumstances.

Under category of fun surprises we passed Joanne & George on SV Bristol Creme. It was great to chat on the radio even more so since missed them in the Bahamas this year. They were heading back to their home waters near New Orleans

As we approached Miami we could see the un-used cruise ships anchored off shore.

We again anchored near Key Biscayne in preparation for our pre-dawn departure.

Stiltsville (https://en.wikipedia.org/wiki/Stiltsville) – its a real place not in a Carl Hiaaasen novel http://www.carlhiaasen.com/ which by the way are the best!!!!

Snug as a bug and ready to head for Palm Beach…

That though is the next episode..thanks again to Mary & Mark for coming out to Key Biscayne!!!

2020-03-15 — Friends, Family, Weddings (Detroit – Orlando).

We always try to stay in touch with friends and so enjoy visitors. Our friends Ron & Nancy (SV Mandala) were visiting in Stuart and took time to run to see us in Palm Beach Gardens. LONG time readers will remember us sharing our “freshen year – 2013” with them and SV EleanorQ. Mandala went on to sail to the Mediterranean and the Caribbean. We learned ALOT from Ron & Nancy that first season and forever grateful.

It was a great visit with Ron & Nancy but we were off and on our way to Detroit well before sunrise the next morning. Awaiting our Uber at Palm Gardens

We did do well on the packing front!

We were off to Detroit to celebrate the wedding of my niece Janine & Rami. As you tell by the snow, we will do anything to support family….snow though????

Events started upon arrival with a mixer at a local place in Royal Oak. The wedding couple plus our whole family included.

My nephew-inlaw Adam is currently deployed so flat Adam stood in…his mother and though were representing and enjoying the festivities.

My beautiful niece and and nephew. Btw, the church is absolutely beautiful. Rami is from Iraq but Chaldean (https://en.wikipedia.org/wiki/Chaldean_Catholics). He and Janine have been together for 8 years and the what I know, Rami is the hardest working person there is. There is much for him to be proud of yet he is the humblest among us. He make my niece smile so that is all there is needed.

My nephew Giacomo and Made of Honor

My Dad stood in for Adam and walked with my niece/his granddaughter Lori

Beautiful couple! Congratulations.

Baker Family (L-R) my brother Jimmy and Angie, my sister Kimberly and Jim, Janine/Rami, my mom and dad.

My mother enjoying the joyous evening.

Father daughter dance, just beautiful!

Brother Jimmy, sister Kimberly and me.

It was a short weekend in Detroit. We did slip in a breakfast with my friend Rosemary and another couple Mick & Denise who hope to be future cruisers. Hopefully you will see them again in this blog!

Returning from Detroit we only had 4 days till the next weekend and there were chores and errands to complete. I mounted my trusty “stead” and headed off.

Even boaters have to wait on bascule bridges though for us….seldom from this side!

My “man-cave” also known as the Pilothouse has been lacking a computer desk. An old barbecue mounting bracket and a trip to the welding shop and very INEXPENSIVE cutting board and poof here you go. Obviously the welding shop was once of the stops along with the required West Marine stop as well.

It was a short week with a few chores and then off to Orlando to attend fellow GevIV cousin Shannon to Colin. Speaking of GenIV, we started the afternoon off with lunch with GenIVs Liam & Carolyn….how many GenIVs you ask??? Too many to count!

All cleaned up coordinated suits with cousin Dan, his wife Lori and my cousin Cathy….MOTHER OF THE BRIDE!!!!! Seems to be happy.

Julie, cousin George and cousin Sean whose wedding we attended last summer!

Cousins Jeanie, Carolyn and the Admiral

Shannon & Colin sure know how to make an entrance!!!

I love this wedding….

A burrito with the Penn Staters…

The Bride & Groom opened their home the day AFTER the wedding for an open-house…looking happy and refreshed!

Beautiful picture!

MaryAnn & Sean still on the honeymoon and looking happy!

Before we knew it was time to head home to Magnolia anf make preps to get underway!

2020-02-24 — Palm Beach Gardens (still)

We have some friends that suggested the best Key Lime Pie is actually at Publix Grocery Store. A quick google drove us to a two mile walk…each way to investigate the legendary Key Lime Pie. It was pretty darn good. A good start to our 5 week stay in Palm Beach Gardens.

Yes of course there is chores. A little epoxy filling required on the teak deck to feel a couple of cracks. On the list is replacement of a few teak plugs but that is for another day,

A winter without these two is just not as fun. Al & Michele from MV Kindred Spirit came to town for a visit. The Loggerhead Sea Turtle Hospital is very close to the Marina so a visit seemed in order. I am happy to report everyone (turtles) seemed to be on the mend. Magnolia and Kindred Spirit both going to Quebec this summer so there was much looking at charts guides. While Al was here it seemed appropriate to take on a small wood working chore. We recently upgraded Pots & Pans and then somewhere along the way it was decided we needed drawer in the cabinet to house said pan….hence the drawer! A visit will Als brother Bill was also on the plan. You might remember Bill who helped with the purchase of Magnolia.

With the sadness of Watsons departure there was but only chores to turn to. A fresh coat of varnish on the NavStation along with installing some additional hand holds eased the pain. Then we had a happy surprise to have Joe & Christine in town to visit his sister Donna & Jack. It was a wonderful couple hour catch up….and then to top it off Al & Michele stopped (I think for Ice Cream) on their way back from the keys!

Roses on Valentines and Head Maintenance for Anthony. The joys on living on a boat. The guy in the shell was showing off and passed me while I was on my bike! For Valentines I went with Annette to a beach cleanup. Sadly it was raining and it was the cleanest beach I have ever seen…I struggled to find a cigarette butt! My niece is getting married this weekend so trying to make myself look respectable…off to Detroit where the forecast high is 27 freaking degrees…

Will let you know if we survive! Be Safe, Vessel and Crew are well.

2020-02-01 Stuart & Palm Gardens

Coming back to Stuart always feels good. It is where our second act of cruising commenced. It is where we found and re-fit Magnolia and where we met lifelong friends who helped make Magnolia what she has become. As I write perhaps some wonder what the hell he is talking about…its a boat, its like a house on the water right? The truth be told she is nothing like that…well to us anyway. Magnolia is our home but she also shows takes us on these wonderful adventures and she keeps us safe and gives us shelter whether that is in a quiet anchorage or 150 miles off the Georgia coast….just feeling grateful…..

Many of our cruising friends pass thru Stuart so its always a great place to catch up. We were able to meet up with MV Unforgettable and MV Way-To-Go along with the bunch of others at the Korgen Breakfasts. We also were lucky enough to meet up with Annette’s Sister Rochelle and Robbins while we were here.

We also had two jobs to complete while in Stuart. One was to replace a solar panel that failed. We pulled the old one in preparation and then….

opened the packing of the replacement. This was not a pleasant sight. Highly unpleasant! Another replacement though arrived meeting us in Palm Beach Gardens.

The other job was to have a small repair made to the pilothouse sole and have two coats of varnish applied. This is Rebelsi giving the deck a good sanding in preparation of the varnish.

This is the result….and of course no shoes are allowed!!

Out last evening in Stuart we able to coordinate a visit with Ted & Lucy Seward from the Pentagon Sailing Club. Ted was Annette’s first “Close Quarters Maneuvering” instructor. Its where is got her start driving Magnolia around docks. Ted & Lucy “winter-over” about 30 min away and it was a real treat to meet up with them.

We were departing the restaurant heading back to Magnolia when we find this guy perched on Blossom, our dinghy. He would not depart until I got in the the dink with him….he left no “presents” thankfully.

We got underway and made the short trip down to Peck Lake which actually nothing more than a wide section of the ICW with a small sit of land between it and the ocean. Beyond the mostly quiet setting you hear the roar of the breaking waves all through the night which is just very cool!

We had a visit from Beverly-S while at Peck Lake. Larry & Sue started their adventure on the west coast in California. What an amazing journey.

Beverly-S at anchor

Sunset on the lake, just beautiful.

After a long weekend visit it was time to head down to Palm Beach Gardens. There is a lot of consternation regarding Florida attempting to crack down on anchored boats in FL. Part of me agrees because this is often what happens when boat get anchored too long.

Annette went to a cooking demonstration at Williams & Sonoma where Ellie Krieger from PBS’s Create Channel was doing book signing…I think she really enjoyed herself.

We will be in Palm Beach Gardens through early March so if you are in the area be sure to let us know. That’s all for now from Magnolia

2020-01-11 — Cocoa Christmas to Stuart, FL

Departing Palm Coast we were on a bit o a weather rush…Annette was heading to Virginia to visit family over Christmas and we needed to be down to Cocoa Village. Mother nature can be a tough task master. Do not cross her, or get underway when she sends you a warning. But somehow on this day the tides, currents and weather all aligned to give us a remarkable passage. We managed 76 miles in one day and we did not even have to work that hard. An amazing day, just when we needed on! Leaving Jeanies house we headed down the coast through New Smyrna, Daytona and into Titusville.

The overnight winds were forecast from the North East so to give us the most comfortable night we anchored to the south of the NASA Causeway providing a terrific wind and wave break.

The next morning as I was doing the morning HAM Radio net I noted a sad thing on shore….

..someone late for work and in a bit of a rush???? Yea, do not miss that! Thankfully Magnolia MIGHT be able to make 15mph….going over Niagara Falls!!!

After my sadness for the car driver abated we got underway and headed the short few miles down to Cocoa where the first couple of days we were expecting strong South East winds. We had never anchored here before so you can see we took a couple of laps around to see find the spot we liked!

We planned to meet our friends Jim & Laurie board SV Kismet. With inclement weather approaching Jim and I decided to take a hike to the grocery store while the ladies stayed dry and did their own thing. Arriving back to the dinghy dock we came a across a highly questionable “Bait & Tackle” shop which really appeared be a dive bar camouflaged as a bait shop…..we were in heaven! A couple of beers, a couple of cigars and toss in the local cast of characters and we were headed for and epic afternoon. Very reminiscent of an afternoon spent in Old San Juan many many years ago!

Notice we could only get in so much trouble with Magnolia and Kismet anchored in a line and the eagle eyed Admirals perhaps on the lookout!

While Jim & Laurie moved on to Vero and Annette jumped a plane to Virginia I was left to my own devices. First up a small lighting upgrade in the galley. The forward end of the galley always struck me as a bit dark.

Next up was a bit of laundry. We have a washer/dryer onboard. I can run the washer off the inverter (no running generator) but do need the generator for the dryer…hence laundry hanging in the Florida sun!

After I got my chores done it was geek-time. I have been experimenting with various sensors aboard Magnolia. I have settled on the Arduino based EPS32 microprocessor. It has low power consumption and built in WIFI. This particular device is measuring the current and voltage of the solar and house battery system. The time is received from a NTP server I run aboard, the temperature and humidity, The current flow from the solar panels and the current flow in/out of the battery followed by voltage and solar production in watts.

A stop in Cocoa is NEVER complete without a stop at Travis Hardware. I don’t know about you but there are few hardware stores that rate a historical marker!!! It is an amazing place and I have never not found what I was looking for….in today’s case some metric speciality screws…crazy, they have EVERYTHING!!!!

Upon Annettes return we made the day trip to Vero Beach where we hoped to meet up with Dan and Marica (SV Cutting Class). Long term readers will undoubtedly recognize the names. We have known them since our very first year underway.

We had a swell evening aboard Magnolia with Jim, Laurie, Marcia and Dan.

We then headed down to Stuart, FL on New Year Day in order to make the scheduled yearly doctor visits.

Once the doctor appointments were complete we headed up river 6 miles to our friends dock.

Magnolia feeling at home on the South Fork of the St Lucie River.

The rest of the story…Greg and Nancy owned Stuart Yachts for I think about 40 years. Greg and Nancy guided us through, and their crew did much of the work restoring Magnolia to a proper yacht. Jenifer, their daughter owned the home we rented during the restoration work. Once again Magnolia made helped us make great friends. Even though Greg is retired, he is still my go-to when it comes to questions regarding the care of this fine vessel. We are blessed to call them friends!

A stop in Stuart is never complete without a visit with Ticonderoga shipmate Mike Camacho and his lovely wife Michele. We commissioned Ticonderoga together back in 1983 and there was much high jinx through the years. See the reference to “an afternoon in Old San Juan” above. I am hoping we can do a boating meet up before we depart the area!!!

We hope everyone had a safe and prosperous holiday. We are keeping all those who are having challenges, health and otherwise in our prayers…we are thinking of all you! Be Safe From Magnolia.

2019-12-25 — St Augustine – Palm Coast

We sure enjoyed our stay in Jacksonville but it was time to move and what better place to visit in the holiday season than St Augustine ( https://en.wikipedia.org/wiki/St._Augustine,_Florida ). You might be able to see the shoaling around the inlet from the ocean, always and area that deserves a little extra attention.

St Augustine Light is always a welcome site. ( https://en.wikipedia.org/wiki/St._Augustine_Light )

Though we have walked through before we have never taken the guided tour of Flagler College. ( https://en.wikipedia.org/wiki/Flagler_College ) previously known as the Pnce Hotel ( https://en.wikipedia.org/wiki/Ponce_de_Leon_Hotel ) . Sitting in the peaceful courtyard was just a perfect moment of relaxation….HIGHLY recommended.

The building and grounds are the former Ponce Hotel and are decorated beyond description! Yes those are Tiffany glass windows and chandeliers!

As always the highpoint of any port visit is the opportunity to meet up with family. Though my Great Uncle Wayne passed away last year we did get to see (L-R) Larry, Barbara, Annette, Anthony, JY, Pam

Carmen slaved in the kitchen for desert so how could we decline?????

We also had a lovely evening with the crew of S/V SeaSprite ( https://www.facebook.com/SeaSprite30/ ). Yes I missed that picture too!!! Obviously we departed St Augustine on the low tide, hence the channel mark laying on its side!!!

We have been dealing with an intermittent issue with out HAM/SSB Radio and two members of the Waterway Radio and Cruising Club ( https://www.waterwayradio.net/ ) stepped forward to help, one with a dock and another with technical assistance. Ridge was quick to determine I had installed a connector incorrectly. With that we were repaired and enjoyed a lovely evening with our dock hosts Jeanie and Bill telling sea stores well past cruisers mid-night!

We were in Palm Coast about 80,miles from Cape Canaveral but had a perfect view of watch the Boeing Atlas launch.

Jeanie came out to see us off! Thank you so much for the hospitality. We much appreciated!

As we headed north we knew we were going to have a good passage with a view like that!

I think the sunshine put everyone (thing) in a good mood because it was not long until the dolphins came out in force to play in our wake!

Ok, and the birds were singing too….I told you it was a great day!

Next time on up to the Cape and Cocoa Village!

2019-12-17 — Jacksonville Wrap – Off To St Augustine

I was expecting a low key wind down to our departure from Jacksonville but that was not to be the case. We kept busy, had a great movie night with Tim & Diane (MV Acadia). Ford vs Ferrari I thought was really really good!

There was also Boys Day over to the Naval Air Station. Tim flew for the Navy and was a great guide! We the boys dont get out and do this enough!

Diane (Acadia), Annette & Ellen (Sea Dweller) enjoy the Avondale Christmas street fair.

Diane (Acadia), Ellen & Jeff (Sea Dweller) Annette

Trying my hand at some gelcoat repair

Ok that is enough work….now for the Tree Trimming & “Toys for Tots” collection

Vicki & Annette enjoying the festivities

Two more fenders, covers and a couple coats of varnish.

A moment of celebration aboard Confetti

After a month in Jacksonville it was time head out. It was a lovely morning making passage down the St Johns River.

Arriving St Augustine and St Augustine Light ( https://en.wikipedia.org/wiki/St._Augustine_Light )

Looking forward to our visit to St Augustine !!!

2019-12-01 — Brunswick GA, Jacksonville FL, Ortega Landing — Thanksgiving Edition

Magnolia departed Brunswick on a cool wet morning with a stretch goal to get down near Jacksonville on the St Johns River so off we went.

We had a pretty good run down to the St Johns River. The one caveat “we” need to remember is the small section in ST Catherines Sound that is kind of (really exposed) in the midst of a north-east wind! Note to self….

In the end we made the trip fine and spent an evening at anchor behind Blount Island off the St Johns River.

The following day we had an easy trip over to Ortega River and Ortega Landing Marina. Our friends on Confetti had made arrangements for us and several other crews to volunteer at a local homeless shelter / soup kitchen. A humbling experience for sure…

Back aboard Magnolia I always have a “big” project I accomplish when we are at the dock for a length of time. This stops project is a lite sanding and a couple coats of varnish on the teak cap-rail.

I did a major job on the cap-rail last year but just wanted to add a maintenance and at the same time improve my application skill. Bottom line, I need more practice though I did better than last year!

Next up was celebrating Thanksgiving. Ortega Landing Marina catered Turkey & Hams and the boats provided the side dishes. Below is our friends Mack & Vicki (Confetti) with their daughter Lucy.

On “Black Friday’ we went back to work at the soup kitchen again. I have to say I “hear” how some people assert the less fortunate are just living off the dole or living off the system etc.I will tell you straight out there was only one person out of about 150 I met that I “felt’ was really working the systems and projected a entitlement attitude. Only one, everyone else was as appreciative as you could be believe. For me this opportunity was a good and humbling experience. This idea people generally want to live off the government I feel is complete BS but thats just my opinion.

We will be heading for St Augustine and then further down the coast next week. We really don’t know where we will be for Christmas yet. Just have to play by ear. Hope this finds everyone safe and well!
